360° monitoring with panorama, double panorama, quad PTZ, single PTZ, and quad-stream modes, H.264 and JPEG triple encoding, Variable Image Quality on Specified area (VIQS) provides up to specified areas with high-quality images without changing the overall size of the data, Super Dynamic and Adaptive Black Stretch (ABS) technologies deliver 128x wider dynamic range, RJ45 Ethernet port with PoE, Electronic day/night for capturing images in low light scenarios, Built-in distortion correction function, Smartphone monitoring, 3D-DNR ensures noise reduction in various conditions, Intelligent Resolution technology automatically detects outlines, detailed textures, and soft gradation areas to perform optimum signal processes for each one for naturally clear and crisp suitable images, Progressive-scan ensures clear images with less motion blur and no tearing even when the subject is moving, Color reproduction by primary (RGB) color filter, Video Motion Detector (VMD) with four programmable detection areas, 15-step sensitivity level, and 10-step detection size
Indoor / Outdoor |
Indoor |
|
---|---|---|
Image sensor |
1/3 MOS |
|
Min. Illumination Color (lx) |
1.5 |
|
Min. Illumination B/W (lx) |
1.2 |
|
Maximum Resolution |
2MP – 3MP (1,080p / 2,048 x 1,536) |
|
Maximum FPS |
30 |
|
Super Dynamic |
Yes |
|
Image compensation |
Adaptive Black Stretch, Digital noise reduction |
|
Color/BW |
Electrical |
|
ABF(Auto back focus)/Auto Focus/Focus Assist |
- |
|
IR LED |
- |
|
Image Stabilizer |
- |
|
Corridor Mode |
- |
|
Privacy Zone |
4 |
|
iA (Intelligent Auto) |
- |
|
Intelligent VMD (i-VMD) |
Type1 |
|
Focal length |
f=0.837mm, F2.4 |
|
Zoom ratio |
- |
|
Angular field of view (16:9) |
H: 188 deg. V: 181 deg. (1:1) |
|
Angular field of view (4:3) |
- |
|
Panning Range |
- |
|
Tilting Range |
- |
|
Network IF |
10Base-T, 100Base-TX, RJ45 connector |
|
Video Codec |
H.264, JPEG |
|
Transmission mode (H.265/H.264) |
Constant bit rate, Advanced variable bit rate, Frame rate, Best effort |
|
Smart Coding |
- |
|
Audio Support |
Yes |
|
Built-in microphone |
Yes |
|
Microphone/Line Input |
Yes |
|
Audio Output |
Yes |
|
SD memory Card Slot |
SDXC |
|
External I/O Terminals |
Yes |
|
Ambient Operating Humidity |
Less than 90 |
|
Vandal Resistant |
- |
|
Water and Dust Resistance |
- |
|
ClearSight Coating / Rain Wash Coating |
- |
|
Dehumidification device |
- |
|
Temperature (degree, Celsius) |
MAX |
50 |
MIN |
-10 |
|
Temperature (degree, Fahrenheit) |
MAX |
122 |
MIN |
14 |
|
Power Source |
PoE, 12V DC |
|
SSL device certificate |
- |
|
ONVIF Profile |
S |
Privacy Zone can mask up to four private areas,
Two-way audio,
Supports microSD card up to 64GB
