Up to 3MP Resolution at 60 fps IR LED for Night Vision Up to 131' 2.8-10mm Varifocal Lens Input and Output for Two-Way Audio
Camera
Sensor | 3 MP 1/3" MOS |
Focal Length | 2.8 to 10mm |
Maximum Aperture | f/1.6 - f/3.4 |
Zoom | Optical: 3.6x |
Lens Field of View | Horizontal: 31 to 112° Vertical: 17 to 60° |
Day/Night | Yes |
Minimum Illumination | Color: 0.0008 Lux B&W: 0 Lux |
Shutter Speed | 1/10000 to 1/30 Seconds |
Video
Streaming Resolution | 2048 x 1536 at 30 fps 1920 x 1080 at 30/60 fps 1280 x 960 at 30 fps 1280 x 720 at 30/60 fps 800 x 600 at 30 fps 640 x 480 at 30 fps 640 x 360 at 30/60 fps 400 x 300 at 30 fps 320 x 240 at 30 fps 320 x 180 at 30/60 fps |
Supported Video Compression | H.264, H.265, H.265+, MJPEG |
Automatic Gain Control | Yes |
Audio
Streaming | Two-Way |
Audio Formats | AAC, G.711, G.726 |
Built-In Mic | No |
External Audio Input | 3.5 mm |
Built-In Speaker | No |
External Audio Output | 3.5 mm |
Networking
Security | HTTPS, IEEE 802.1X |
Supported Protocols | ARP, DDNS, DHCP, DNS, DiffServ, FTP, HTTP, ICMP, IGMP, IPv4/v6, NTP, RTCP, RTP, RTSP, SMTP, SNMP v1/v2c/v3 (MIB-II), TCP, UDP, UPnP |
System Integration
Event Trigger | Yes |
Event Action | Recording, Notification, Alarm |
System Requirements
Mobile Operating Systems | iOS, Android |
Environmental
Operating Temperature | -22 to 140°F / -30 to 60°C |
Operating Humidity | 10 to 100% |
IP Rating | IP66 |
IK Rating | IK10 |
General
Recording Media | SD (up to 256 GB) |
Pan/Tilt | Manual Pan: 180° Manual Tilt: 100° |
Alarm I/O | 3 / 1 |
I/O Connections | 1 x Power 1 x RJ45 1 x RCA |
IR Range | 131.23' / 40 m |
Supported Languages | English French German Italian Japanese Portuguese Russian Spanish Traditional Chinese |
Certifications | CSA, IEC60950-1, UL, EN 55024, EN 55022 Class B, ICES-003 Class A, FCC (Part 15 Class A), as per Manufacturer |
Internal Storage | None |
Power Source | DC, PoE 802.3af (15 W) |
Power Consumption | DC: 9 W PoE: 9.4 W |
Material of Construction | Aluminum |
Dimensions | H: 5.1 x W: 5.1 x L: 13.3" / H: 130.0 x W: 130.0 x L: 337.0 mm |
Weight | 3.53 lb / 1.6 kg |
Packaging Info
Package Weight | 6.315 lb |
Box Dimensions (LxWxH) | 19.6 x 7.3 x 6.4" |
Auto shutter speed control for fast moving vehicles
Low-light performance in true color with low noise for night time applications
Super Dynamic 144 dB for backlit situations involving headlights and shadows
IP66 and IK10 rated
Self-learning ROI encoding (Auto VIQS) detects movement within frame and compresses the areas with little motion to reduce transmitted data while maintaining the quality of the image
Smart facial coding adds bandwidth reduction for ID camera applications
Full encryption SD card edge recording to keep your data safe
FIPS 140-2 Level 1 compliant
Full end-to-end system encryption with supported VMS and devices to protect from IP snooping/spoofing and detect data alteration
