HARDWARE FEATURE | |
Frequency Bandse | 2.4GHz/5GHz |
PHY Data Rates | 1200Mbps |
Wi-Fi Standards | IEEE 802.11n/g/b? 802.11ac/n/a |
Interfaces | 1*10/100/1000Mbps PoE/LAN port? 1*DC Power Jacket |
Buttons | 1*RESET |
Antennas | 2x Integrated dualband, Omni-directional, 4dBi gain |
Max Power Consumption | 17W |
LED Indicator | PWR, 2.4G?5G |
Power Supply | DC Input: 12 VDC 1.5A PoE: 802.3at compliant |
Receiver Sensitivity | MCS0: -88dBm MCS7: -72dBm |
SOFTWARE FEATURE | |
Operating mode | AP,WDS,Client+AP |
WiFi Radio | Enable or Disable |
BSSIDs | Up to 8 (2.4 GHz), Up to 4(5 GHz) |
SSID hiding | Enable or Disable |
Clients Limit | Connected user number limitation for every SSID |
VLANs | 802.1Q, 4094 VLAN IDs (1 to 4094) and SSID-based VLAN assignment |
Adjustable Power | Adjustable step by 1dBm |
Access Control | Connect limitation based on mac address |
Wireless Security | 64/128 WEP,WPA-PSK,WPA2-PSK,WPA&WPA2-PSK,WPA,WPA2 |
VPN Pass-Through | PPTP,L2TP |
System Monitoring | Status Statistic and Event Log |
Working Environment | |
Operating Temperature | -10?~40? |
Storage Temperature | -30?~70? |
Operating Humidity | 10%?90% (non-condensing) |
Storage Humidity | 10%?90% (non-condensing) |
