| Form Factor |
2U Rackmount |
| Daya Keluar |
1000VA / 700W |
| Voltase Masuk |
- Nominal Input Voltage : 230V
- Input Frequency : 50/60 Hz +/- 5 Hz (auto sensing)
- Input Connections : IEC-320 C14
- Input voltage range for main operations : 160 - 280V
- Input voltage adjustable range for mains operation : 100 - 280V
- Other Input Voltages : 220, 240
|
| Voltase Keluar |
230Vac
- Waveform Type : Sine wave
- Output Connections :
- (6) IEC 320 C13
- (2) IEC Jumpers
|
| Surge Energy Rating |
420 joules
- Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
|
| Back-Up Time Half Load |
32 minutes |
| Back-Up Time Full Load |
14 minutes |
| Antarmuka / Interface |
- 1x Serial RS-232 (DB-9) Port
- SmartSlot
|
| Baterai |
Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
- Internal Battery : 31.7 Minutes
- Included Battery Modules 1
- Typical recharge time 3 hour(s)
- Replacement Battery RBC31
- Internal Battery + 1 SURT48XLBP : 140.6 Minutes
- Internal Battery + 2 SURT48XLBP : 257.5 Minutes
- Internal Battery + 3 SURT48XLBP : 379.1 Minutes
- Internal Battery + 4 SURT48XLBP : 504 Minutes
- Internal Battery : 14 Minutes
- Internal Battery + 1 SURT48XLBP : 69.5 Minutes
- Internal Battery + 2 SURT48XLBP : 129.2 Minutes
- Internal Battery + 3 SURT48XLBP : 191.2 Minutes
- Internal Battery + 4 SURT48XLBP : 255 Minutes
|
| Dimensi |
(85 x 432 x 483 mm) WHD |
| Berat |
23.09 kg |
| Kelengkapan Paket |
- CD with software
- Smart UPS signalling RS-232 cable
- User Manual
|
