| Form Factor |
Tower |
| Daya Keluar |
1000VA / 800W |
| Voltase Masuk |
- Nominal Input Voltage : 230V
- Input Frequency : 47 - 63 Hz
- Input Connections : IEC-320 C20
- Cord Length : 1.22 meters
- Input voltage range for main operations : 160 - 280V
- Input voltage adjustable range for mains operation : 100 - 280V
- Other Input Voltages : 220, 240
|
| Voltase Keluar |
- Output Power Capacity : 800 Watts / 1000 VA
- Max Configurable Power : 800 Watts / 1000 VA
- Nominal Output Voltage : 230V
- Output Voltage Note : Configurable for 220 : 230 or 240 nominal output voltage
- Efficiency at Full Load : 88.0%
- Output Voltage Distortion : Less than 2%
- Output Frequency (sync to mains) : 50/60Hz +/- 3 Hz
- Other Output Voltages : 220, 240
- Crest Factor : 3 : 1
- Topology : Double Conversion Online
- Waveform Type : Sine wave
- Output Connections : (4) IEC 320 C13
- Efficiency at Half Load : 82.0%
- Bypass : Built-in Bypass
|
| Surge Energy Rating |
- Surge energy rating : 420 Joules
- Filtering :
- Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
|
| Dataline Protection |
RJ-45 Modem/Fax protection (four wire dual line) |
| Back-Up Time Half Load |
|
| Back-Up Time Full Load |
|
| Antarmuka / Interface |
Serial RS-232 (DB-9) Port, Smart-Slot
1
|
