Display
|
- Diagonal Size: 55"
- Panel Type: New Edge, 60 Hz
- Resolution: 3,840 x 2,160
- Pixel Pitch (HxV, mm): 0.105 x 0.315
- Brightness (Typical, cd/m2): 500
- Contrast Ratio: 4,000 : 1
- Viewing Angle (H/V): 178 / 178
- Response Time: 8 ms
- Color Gamut: 72 %
- Glass Haze: 0.25 %
- H-Scanning Frequency: 30 ~ 81 kHz
- Maximum Pixel Frequency: 594 MHz
- V-Scanning Frequency: 48 ~ 75 Hz
- Contrast Ratio (Dynamic): Mega
|
|
Connectivity
|
- HDMI In: 2
- DP In: Yes
- DVI In: 1
- USB: 2
- IR In: Yes
- HDBaseT In: No
- Audio In: Yes
- Audio Out: Stereo Mini Jack
- Video Out: Yes
- RS232 In: Yes
- RS232 Out: Yes
- RJ45 In: Yes
- RJ45 Out: No
- WiFi: Yes
- Bluetooth: Yes
|
|
Power
|
- Power Supply AC100-240V 50/60Hz
- Power Consumption (On Mode) 143 W
- Power Consumption (Sleep Mode) 0.5 W
|
|
Dimension
|
- Set Dimension (WxHxD) 1235.1 x 707.9 x 46.3 mm
- Package Dimension (WxHxD) 1402 x 858 x 163 mm
|
|
Mechanical Specification
|
- VESA Mount 200 x 200 mm
- Bezel Width (mm) 9.2 (U/L/R), 11.2 (D)
- Frame Material Non-Glossy
|
|
Optional Feature
|
|
