RP. 69,938,000
- The machine provides 48 Gigabit POE electrical ports, 2 Gigabit SFP optical ports, and 2 10 Gigabit SFP+ optical ports;
- Support IEEE 802.3af/at power supply standard, the maximum output of a single port is 30W, and the maximum output of the whole machine is 850W;
- Support fat and thin mode switching, zero configuration online management in thin mode, realize plug and play;
- Support wireless AC centralized configuration management, including port information, VLAN, port switch, etc.;
- Support Voice Vlan function, can access IP telephone equipment, unify telephone network and computer network as a whole;
- Support visual status check, including switch load, forwarding load, online status, switch status;
- With security features, support linkage with wireless network equipment and security equipment to achieve safer network management and control;
- To meet the needs of large-scale networking, suitable for large-scale campus network, enterprise network, IP metropolitan area network construction access equipment;
| model | RS5300-52X-PWR-SI | Applicable scene | Enterprise network, campus network, metropolitan area network |
| Number of interfaces |
48* Gigabit POE electrical port; 2*Gigabit SFP optical port; 2*10G SFP+ optical port. |
Other interface |
1*CONSOLE port; 1*MANAGE mouth; |
| Exchange capacity | 336Gbps/3.36Tbps | Packet forwarding rate | 144Mpps/166Mpps |
| Access method | Fat and thin one (support switching) | Online method | Layer 2 broadcast/static IP address/DHCP Option43/DNS domain name |
| Spanning tree | STP, RSTP, MSTP protocols | Routing function |
Support IPv4/IPv6 static routing; Support RIPv1/2, OSPF and other IPv4 dynamic routing; Support IPv4 policy routing; ARP table ≥512 |
| Multicast |
Support IGMP v1/v2/v3 snooping; Multicast entry ≥ 1K |
VLAN | 4K |
| Mirror | Support port mirroring | Flow Control | Support ACL, QoS |
| Access security |
Support DHCP Relay, DHCP Server; Support DHCP Snooping; Support Portal authentication; Support 802.1X authentication; Support blacklist and whitelist |
reliability |
Support VRRP, BFD for VRRP; Support BFD for RIP/OSFP/static routing/policy routing; Support Smartlink (backup link); Support Monitor-link (uplink monitoring) |
| MAC | 32K, support automatic learning, filtering, learning limit | Security features | Anti-ARP spoofing, administrator hierarchical management, port protection/isolation, anti-DOS/ARP attack, CPU protection, border terminal security management |
| Port aggregation | 128, support manual, static LACP | Virtualization |
Support vUnit (stacking technology, virtualize multiple devices into one) Support M-LAG, cross-device link aggregation, paired devices have independent control plane |
| Network management | APP remote management, remote management across WAN/NAT | Switch portrait | Support visual viewing |
| power supply | Built-in power supply | Lightning protection | 9KV |
| POE output | Maximum 850W | fan | Built-in fan module |
| Safety | FCC, CE, RoHS | EEE | Energy-saving technology supporting IEEE 802.3az standard |
| Operating temperature | -5℃～45℃ | storage temperature | -40℃～70℃ |
| Working humidity | 5%～90% RH (no condensation) | physical dimension | 440mm x 330mm x 44mm |
|
Unit Termasuk |
Unit Utama |
