| Package Contents |
- VC320 main unit
- Remote control
- Power adapter
- 5M USB cable
- HDMI cable
- Quick-start guide
|
| Camera |
- Full HD 1080p at 30 frame per second
- UVC1.1 YUV/MJPEG with H.264 extension
- Glass multi-coating lens with 110° field of view
- F-stop: F2.0
- 5X zoom (including 1.7X lossless zoom)
- Smooth and fast electronic pan, tilt and zoom
- Manual tilt: ±10°
- Fixed-focus lens support 1 meter to infinity
- EZCrop* one button auto crop all faces detected into full frame (*button on remote control)
- Camera privacy shutter button
|
| Speakerphone |
- Integrated full duplex speakerphone with echo cancellation and noise suppression
- 360° wideband audio with 15-foot diameter range
- USB, Bluetooth and NFC enabled
- Bluetooth: HFPF, HSP, A2DP, BLE; Bluetooth 4.0 Class II 10M range
- Capable of bridging USB and Bluetooth call
- Mute button on remote, LED indicator on unit
|
| Microphones (Tx) |
- 1 omni-directional microphones
- Frequency response: 100Hz – 16 KHz
- Sensitivity: -36dB +/-3dB
- Distortion: <1% @ 1KHz at 110dB
|
| Speakers (Rx) |
- Frequency response: 270Hz – 16KHz
- Sensitivity: 80dBSPL +/-3dB at 1W/1M
- Max output: 90dBSPL at 0.5M
- Distortion: <5% at 179Hz – 10kHz
- 5W speaker
|
| Remote Control |
- Dockable infra-red remote control
|
| Screen Mirroring |
- HDMI input and output
- 2.1A port for powering Chromecast or specified 3rd party wireless display adapter for wireless screen mirroring
|
| Convenience and Security |
- Battery life: up to 2 hours videoconferencing or 8 hours Bluetooth audio call
- Battery rechargeable through AC power (adapter included)
- Time to fully charge battery (from AC power, device idle): 3 hours
- Standard tripod thread
- Kensington security slot
|
|
System requirement
|
- Windows® 7/ 8/8.1/10
- Mac OS® X 10.7 or higher
- Google Chromebook version 29.0.1547.70, Platform 4319.79.0 with:
- 2.4GHz Intel Core 2 Due Processor
- 2GB RAM or more
- Hard drive space for recorded videos
- USB 2.0 port
|
| Compliance and Tools |
- YUV, MJPEG, H.264 SVC*, AVC (high and base profile)
- USB 2.0 UVC (USB Video Class) 1.1 with H.264 extension
- HDMI 1.3
- *this feature will be available in the future
|
| Compatible Applications |
- Skype™, Skype for Business, V-CUBE, Google Hangouts™, FaceTime®, Cisco Webex®, GoToMeeting®, Adobe® Connect™, BlueJeans, Zoom, Vidyo®, Fuze, WebRTC, CyberLink U Meeting®
|
| Power Supply |
- AC100V ~ 240V
- Consumption: 12V/2A
|
