| Package contents |
- Camera
- Remote control
- 5m USB cable to PC (USB2.0 mini B to PC)
- Power supply
- Quick-start guide
- Tabletop/wall/ceiling mount
- 6.35mm tripod mounting screw
- Velcro
- 3m HDMI cable
- RS232 adapter
|
| Camera |
- Full HD 1080p 60fps
- Pan: ±130°; 0.45° step
- Tilt: +90°/-25°; 0.25° step
- Field of view (H): 72.5° (wide) ~ 6.3° (tele)
- Sensor: 1/2.8 low lux CMOS 2M pixel
- Resolution: full HD 1080p (1920x1080), HD 720p (1280x720), PAL (1024x576), VGA (640x480), QVGA (320x240), QQVGA (160x120) at 60fps, 30fps and 15fps
- Scan: progressive
- Zoom: 18X total zoom (12X optical zoom)
- Lens focal length: 3.9mm (wide) ~ 47.3mm (tele)
- Lens F#: 1.8 (wide) ~ 2.8 (tele)
- Auto Iris
- S/N ratio: >50dB
- Minimum illumination: 1 lx (50 IRE, F1.6, shutter 1/30)
- 2D and 3D denoise
- Backlight compensation
- Flip, mirror
- Minimum working distance: 1.5 meter
- Include table/wall/ceiling mount
- Kensington slot
|
| Remote Control |
- IR (Infrared)
- 10 camera presets (100 presets via VISCA)
|
| System Requirement |
- Windows 7/8/8.1/10
- Google Chromebook version 29.0.1547.70 Platform 4319.79.0
- Mac OS X 10.7 or higher
|
| Hardware Spec |
- 2.4GHz Intel® Core 2 Duo processor
- 2GB RAM or more
- USB 2.0 port
|
| Power Supply |
- AC 100V ~240V
- Consumption: EIAJ 12, 4A
|
|
Compliance and Tools
|
- YUV, MJPEG, H.264 SVC, AVC (high and base profile)
- Multi-stream capable
- USB 2.0
- UVC (USB Video Class) 1.1 with H.264 extension
- VISCA via RS232*
- HDMI 1.3
- DIP Switch
- Downloadable diagnostic tool, field firmware upgrade tool, App for advanced features and settings
|
