Extreme image quality for evidence capturing under challenging conditions - Clear and less distorted image of the person's face and objects at the edge of the fisheye - Instant response to sudden light changes like tunnel entry and exit - Auto Shutter speed control for fast moving objects - Super Dynamic 108dB for backlit situations and shadows on night streets - Built-in IR LED to produce a clear monochrome image in zero lux conditions with 10 m (33 feet) irradiation distance - Environmental durability : EN50155, IP66, IK10, 50J and electric dehumidifier Extreme H.265 compression with new Smart Coding (Click here for details) - Longer recording and less storage space compared to any H.264 based compression techniques - New self-learning ROI* encoding (Auto VIQS) dynamically detects motion areas to keep vehicles and humans in good picture quality while lowering your bandwidth * Region of Interest Extreme Data Security - Full encryption SD card edge recording to keep your data safe - FIPS 140-2 Level 1 compliant - Full end-to-end system encryption with supported VMS and devices to protect from IP snooping/spoofing and detect data alteration Complete with powerful analytics built-in* - Heat map : Visualization of people's traffic pattern and staying times - People Counting : Statistics data on the number of people entering and leaving a specific zone - MOR (Moving Object Remover) : Monitoring of only the surrounding environment by removing people and other moving objects from video *To enable analytics, please add the optional WV-SAE200 software.
Indoor / Outdoor |
Outdoor |
|
---|---|---|
Image sensor |
1/3 MOS |
|
Min. Illumination Color (lx) |
0.3 |
|
Min. Illumination B/W (lx) |
0.04 / 0 (w/IR-LED) |
|
Maximum Resolution |
5MP (2,192 x 2,192) |
|
Maximum FPS |
30 |
|
Super Dynamic |
Yes |
|
Image compensation |
Adaptive Black Stretch, Back light compensation (BLC), Fog compensation, High light compensation (HLC), Digital noise reduction |
|
Color/BW |
ICR |
|
ABF(Auto back focus)/Auto Focus/Focus Assist |
- |
|
IR LED |
Yes |
|
Image Stabilizer |
- |
|
Corridor Mode |
- |
|
Privacy Zone |
8 |
|
iA (Intelligent Auto) |
Yes |
|
Intelligent VMD (i-VMD) |
Type5 |
|
Focal length |
f=0.84mm, {1/32 inches}, F2.4 |
|
Zoom ratio |
- |
|
Angular field of view (16:9) |
H: 186 deg. V: 186 deg. (1:1) |
|
Angular field of view (4:3) |
- |
|
Panning Range |
-5 deg. 0 deg. +5 deg. |
|
Tilting Range |
- |
|
Network IF |
10Base-T, 100Base-TX, RJ45 connector, M12 connector |
|
Video Codec |
H.265, H.264, JPEG |
|
Transmission mode (H.265/H.264) |
Constant bit rate, Variable bit rate, Frame rate, Best effort |
|
Smart Coding |
Yes |
|
Audio Support |
Yes |
|
Built-in microphone |
- |
|
Microphone/Line Input |
Yes |
|
Audio Output |
Yes |
|
SD memory Card Slot |
SDXC |
|
External I/O Terminals |
Yes |
|
Ambient Operating Humidity |
10-100 |
|
Vandal Resistant |
IK10 (IEC62262), 50J (IEC60068-2-75) |
|
Water and Dust Resistance |
IP66 (IEC60529), Type 4X(UL50), NEMA 4X |
|
ClearSight Coating / Rain Wash Coating |
- |
|
Dehumidification device |
Yes |
|
Temperature (degree, Celsius) |
MAX |
60 / 50 (w/IR-LED) |
MIN |
-40 |
|
Temperature (degree, Fahrenheit) |
MAX |
140 / 122 (w/IR-LED) |
MIN |
-40 |
|
Power Source |
PoE, 12V DC |
|
SSL device certificate |
Yes |
|
ONVIF Profile |
S, G, T |
|
Note |
WV-S4550L : RJ45 connector, WV-S4550LM : M12 connector |
*To enable analytics, please add the optional WV-SAE200 software.
