| Form Factor |
2U Rackmount |
| Daya Keluar |
1000VA / 700W |
| Voltase Masuk |
- Nominal Input Voltage : 230V
- Input Frequency : 50/60 Hz +/- 3 Hz (auto sensing)
- Input Connections : IEC-320 C14
- Input voltage range for main operations : 160 - 286V
- Input voltage adjustable range for mains operation : 151 - 302V
- Other Input Voltages : 220, 240
|
| Voltase Keluar |
- Nominal Output Voltage : 230V
- Output Voltage Note : Configurable for 220 : 230 or 240 nominal output voltage
- Output Voltage Distortion : Less than 5% at full load
- Output Frequency (sync to mains) : 47 - 53 Hz for 50 Hz nominal, 57 - 63 Hz for 60 Hz nominal
- Other Output Voltages : 220, 240
- Waveform Type : Sine wave
- Output Connections :
- (4) IEC 320 C13
- (2) IEC Jumpers
|
| Surge Energy Rating |
459 Joules
- Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
|
| Back-Up Time Half Load |
31 minutes |
| Back-Up Time Full Load |
9 minutes |
| Antarmuka / Interface |
RJ-45 Serial, SmartSlot, USB |
| Baterai |
- Battery Type : Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
- Typical recharge time : 3 hour(s)
- Replacement Battery : APCRBC132
- RBC
