| Data Rates |
- 802.11a : 6,9,12,18,24,36,48,54 Mbps
- 802.11b : 1, 2, 5.5, 11 Mbps
- 802.11g : 6,9,12,18,24,36,48,54 Mbps
- 802.11n : up to 600 Mbps
- 802.11ac: up to 1734 Mbps
- 1024QAM (2.4GHz) : up to 1000 Mbps
- 1024QAM (5GHz) : up to2167 Mbps
|
| Encryption |
- 64-bit WEP, 128-bit WEP, WPA2-PSK, WPA-PSK, WPA-Enterprise , WPA2-Enterprise , Radius with 802.1x, WPS support
|
| Lain-lain |
- Firewall & Access Control
- Firewall: SPI intrusion detection,DoS protection
- Access control: Parental control, Network service filter, URL filter, Port filter
- Management : UPnP, IGMP v1/v2/v3, DNS Proxy, DHCP, SNMP, NTP Client, DDNS, Port Trigger, Virtual Server, DMZ, System Event Log
- VPN Support
- IPSec Pass-Through
- PPTP Pass-Through
- L2TP Pass-Through
- PPTP server
- OpenVPN server
- PPTP client
- L2TP client
- OpenVPN client
- WAN Connection Type : Internet connection type : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP
- Utilities
- Printer Server : multifunctional printer support(Windows nly), LPR protocol support
- File server : Samba and FTP server with account management
- PPTP VPN server
- Network map
- Traffic Analyzer
- Guest Network : 2.4GHz guest network x 3, 5GHz-1 guest network x 3, 5GHz-2 guest network x 3
- Link Aggregation
- MU-MIMO
- Airtime Fairness
- Smart Connect
- Adaptive QoS
- Parental Control
- Mac OS Backup
- Dual WAN
- IPTV support
- Roaming Assist
- Download master :
- Support BT, NZB, HTTP, ED2K
- Support encryption, DHT, PEX and magnet link
- Upload and download bandwidth control
- Download scheduling
- Media server :
- Image : JPEG
- Audio : mp3, wma, wav, pcm, mp4, lpcm, ogg
- Video : asf, avi, divx, mpeg, mpg, ts, vob, wmv, mkv, mov
- Product Segment : AC5300 ultimate AC performance:1000+2167+2167 Mbps
- Memory
- Wi-Fi Technology
- Beamforming: standard-based and universal
- 1024-QAM high data rate
- 20/40/80 MHz bandwidth
- WPS Button, Reset Button, Power Button, Wireless on/off Button
|
