| Firewall Throughput (1518 / 512 / 64 byte UDP packets) |
3 / 3 / 3 Gbps |
| Firewall Latency (64 byte UDP packets) |
3 ?s |
| Firewall Throughput (Packets Per Second) |
4.5 Mpps |
| Concurrent Sessions (TCP) |
1.3 Million |
| New Sessions/Second (TCP) |
30,000 |
| Firewall Policies |
5,000 |
| IPsec VPN Throughput (512 byte packets) |
2 Gbps |
| Gateway-to-Gateway IPsec VPN Tunnels |
200 |
| Client-to-Gateway IPsec VPN Tunnels |
500 |
| SSL-VPN Throughput |
150 Mbps |
| Concurrent SSL-VPN Users (Recommended Maximum) |
100 |
| IPS Throughput (HTTP / Enterprise Mix) 1 |
1,400 / 350 Mbps |
| SSL Inspection Throughput 2 |
340 Mbps |
| Application Control Throughput 3 |
550 Mbps |
| NGFW Throughput 4 |
250 Mbps |
| Threat Protection Throughput 5 |
180 Mbps |
| CAPWAP Throughput 6 |
1.5 Gbps |
| Virtual Domains (Default / Maximum) |
10 / 10 |
| Maximum Number of FortiAPs (Total / Tunnel Mode) |
10 / 5 |
| Maximum Number of FortiTokens |
100 |
| Maximum Number of Registered FortiClients |
200 |
| High Availability Configurations |
Active / Active, Active / Passive, Clustering |
