| Type |
Desktop |
| Maximum Original Size |
A3 |
| Copy Sizes |
Cassette 1, 2: |
A4 |
| Cassette 3, 4: |
A3, A4, A4R, A5R
Custom Size 139.7 x 182mm to 297 x 487.7mm |
| Multi Purpose Tray: |
A3, A4, A4R, A5R
Custom Size 100 x 148mm to 297 x 487.7mm |
| Resolution |
Reading: |
600 x 600dpi |
| Copying: |
600 x 600dpi |
| Printing: |
1200 x 1200dpi (text / line only) |
| Copy / Print Speed |
A4: |
65ppm (Black & White) |
|
A3: |
32ppm (Black & White) |
| Magnification |
Copy Ratio: |
25 - 400% |
| First Copy Out Time |
3.3 seconds or less |
| Warm-Up Time |
38 seconds or less |
| Multiple Copies / Prints |
1 to 9,999 copies |
| Paper Weight |
Cassette: |
52 to 220gsm |
| Multi Purpose Tray: |
52 to 256gsm |
| Paper Capacity |
Cassette 1, 2: |
1,500 sheets x 2 cassettes (80gsm) |
| Cassette 3, 4: |
550 sheets x 2 cassettes (80gsm) |
| Multi Purpose Tray: |
100 sheets (80gsm) |
| Paper Deck: |
3,500 sheets (80gsm) |
| CPU |
1.2GHz |
| Memory |
Standard: |
1.5GB RAM |
| Maximum: |
2GB RAM |
| Hard Disk Drive |
Standard: |
80GB |
| Maximum: |
250GB |
| Interface |
Ethernet (1000BaseT / 100Base-TX / 10Base-T)
Wireless LAN (IEEE802.11b/g, Optional), USB 2.0 |
| Power Supply |
220 - 240V AC, 50 / 60Hz, 10A |
| Power Consumption |
Max. 2.2kW or less; when in sleep mode 1.5W or less |
| Dimensions (H x W x D) |
1,040 x 645 x 770mm (with platen cover)
1,220 x 645 x 770mm (with DADF)
1,252 x 1,481 x 770mm (with DADF and Upright Control Panel) |
| Weight |
Approx. 237kg (with toner bottle and DADF) |
|
|
| PDL |
UFRII (Standard), PCL5e / 6 (Optional), Adobe PostScript 3 (Optional) |
| Resolution |
1200 x 1200dpi (text / line only) |
| Memory |
2GB (Uses Main unit RAM) |
| Hard Disk |
Standard: |
80GB |
| Maximum: |
250GB |
| CPU |
Canon Custom Processor, 1.2GHz (Uses Main unit CPU) |
| PS Fonts |
Roman 136 |
| PCL Fonts |
Roman93, Bitmap10, OCR2 |
| Supported OS |
PCL: |
Windows 2000 / XP / Server 2003 / Vista / Server 2008 / Win7 |
| Adobe PostScript 3: |
Windows 2000 / XP / Server 2003 / Vista / Server 2008 / Win7, Mac OSX 10.4.9 or later |
| UFR II |
Windows 2000 / XP / Server 2003 / Vista / Server 2008 / Win7,
Mac OSX 10.4.9 or later |
| Mac-PPD |
Mac OS 9.1 or later, Mac OSX 10.2.8 or later |
| Interface |
Ethernet (1000Base-T / 100Base-TX / 10Base-T)
Wireless LAN (IEEE802.11b/g, Optional), USB 2.0 |
| Network Protocol |
TCP / IP (LPD / Port9100 / WSD / IPP / IPPS / SMB / FTP), IPv6, IPX /
SPX (NDS, Bindery), AppleTalk |
| Pull Scan |
Network TWAIN Driver
(75 to 600dpi 24 bits colour / 8 bits grayscale / 2 bits Black & White) |
|
|
| Scan Speed (A4, 300dpi) |
Black & White: |
120ipm |
| Colour: |
85ipm |
| Resolution |
600 x 600dpi |
| Destinations |
E-Mail / Internet FAX (SMTP), PC (SMB, FTP), iWDM, WebDAV |
| Address Book |
LDAP, Local (Max. 1800) |
| File Format |
TIFF, JPEG, PDF, XPS, High compression PDF / XPS, PDF / A-1b, Optimize PDF for Web |
