| Form Factor |
Tower |
| Daya Keluar |
3000VA / 2100W |
| Voltase Masuk |
- Nominal Input Voltage : 230V
- Input Frequency : 50/60 Hz +/- 5 Hz (auto sensing)
- Input Connections : IEC-320 C20
- Cord Length : 2.44 meters
- Input voltage range for main operations : 160 - 280V
- Input voltage adjustable range for mains operation : 100 - 280V
- Other Input Voltages : 220
- Input Breaker Capacity : 20 A
|
| Voltase Keluar |
- Output Power Capacity : 2100 Watts / 3000 VA
- Max Configurable Power : 2100 Watts / 3000 VA
- Nominal Output Voltage : 230V
- Output Voltage Note : Configurable for 220 or 230V nominal output voltage
- Efficiency at Full Load : 89.0%
- Output Voltage Distortion : Less than 3%
- Output Frequency (sync to mains) : 50/60 Hz +/- 3 Hz user adjustable +/- 0.1
- Other Output Voltages : 220
- Crest Factor : 3 : 1
- Topology : Double Conversion Online
- Waveform Type : Sine wave
- Output Connections :
- (1) Hard Wire 3-wire (H N + G)
- (8) IEC 320 C13
- Bypass : Built-in Bypass
|
| Surge Energy Rating |
- Surge energy rating : 420 Joules
- Filtering :
- ull time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
|
| Dataline Protection |
RJ-45 Modem/Fax protection (four wire dual line) |
| Back-Up Time Half Load |
|
| Back-Up Time Full Load |
|
| Antarmuka / Interface |
Serial RS-232 (DB-9) Port, Smart-Slot
