RUIJIE REYEE RG-CS86-20XS4VS2QXS-D -

RUIJIE REYEE RG-CS86-20XS4VS2QXS-D

20 x 10GE SFP+ ports (Compatible with 2.5GE), 4 x 25GE SFP28 ports, and 2 x 40GE QSFP+ ports for uplink
VSU, realizing flexible networking and high performance
Hardware-level multi-protection, ensuring service continuity
Network security policies and real-time monitoring, enhancing network robustness
Comprehensive QoS policies for flexible network resource allocation and stable services
Diverse network management modes, enabling simple maintenance

Fixed service port	Number of 10GE 20 x 1GE/2.5GE/10GE SFP+ ports 4 x 10GE/25GE SFP28 ports 2 x 40GE QSFP+ ports Note: One switch provides a maximum of 32 x 10GE ports.
System Specifications	570 Mpps, 760Gbps(bit/s)
Dimensions and Weight	440 mm x 330 mm x 43.6 mm, 6.4 kg
Power supply	RG-PA150I-F (AC input): ● Rated input voltage: 100 V AC to 240 V AC, 50 Hz to 60 Hz ● Maximum input voltage: 90 V AC to 264 V AC, 47 Hz to 63 Hz ● Maximum input current: 3 A 150 W
Humidity	Operating humidity: 10% to 90% RH (non-condensing) Storage humidity: 5% to 95% RH (non-condensing)
Security	Port isolation Broadcast storm control
