Ruckus ICX 7150 Switch (ICX7150-24-2X10G)
RP. 32,744,300
  • Managed switch
  • ICX 7150 Switch
  • 24 x 10/100/1000 Mbps RJ45
  • 4 x 1/10 Gbps SFP/SFP+ uplinks
  • 24 x PoE/PoE+ ports
  • Switching capacity: 132 Gbps
  • Stacking ports: Up to 4×10 GbE SFP+

Input Frequency

  • 50 to 60 Hz

Power Supply

  • Power supply rated maximum: 525 W; PoE power budget (AC): 370 W

Ports

  • Up to 4×10 GbE SFP+
  • 24 x PoE/PoE+ ports

Kelengkapan Paket

  • ICX 7150 Switch, 24x 10/100/1000 PoE+ ports, 2x 1G RJ45 uplink-ports, 4x 1G SFP uplink ports upgradable to up to 4x 10G SFP+ with license, 370W PoE budget, basic L3 (static routing and RIP) [ICX7150-24P-4X1G], USB 2.0 CABLE, TYPE-C TO TYPE-A, 1M [CC-USBC-USBA], Power Cord for RPS2/3/5/9, European version [PCEURO]

Others

  • Connector options: 10/100/1000 Mbps RJ-45, 1 Gbps SFP ports, 1/10 Gbps SFP+ ports, Out-of-band Ethernet management: 10/100/1000 Mbps RJ-45, Console management: RJ45 serial port and USB Type-C port with serial communication device class support, File transfer: USB port, standard-A plug
  • DRAM: 1GB
  • NVRAM (Flash): 2GB
  • Packet buffer size: 12/24 port: 2 MB, 48 port: 4 MB
  • 24 x 10/100/1000 Mbps RJ45 downlinks
  • 2 x 10/100/1000 Mbps RJ45 uplinks
  • 4 x 1/10 Gbps SFP/SFP+ uplinks
  • 24 x PoE/PoE+ ports
  • 24 x Maximum PoE Class 3 ports
  • 12 x Maximum PoE+ Class 4 ports
  • Aggregated stacking bandwidth: 480Gbps

Output Voltage

  • 100 to 240 VAC

Unit Termasuk

Unit Utama
