| Package Contents |
- VB342 unit
- Remote control
- 1.8m USB cable to PC (USB 3.0 type C to PC)
- USB type-A to type-C adapter
- Power supply
- Quick-start guide
- Wall mount bracket
- Mounting screws
|
| Camera |
- Sensor: 1/2.5"Sony Exmor RTM 4K CMOS sensor
- Frame rate: 4K 30fps; 1080p, 720p, 960x540, 848x480, 640x480, 640x360, 424x240, 320x240, 320x180 at 60, 30, 15 fps
- Lens iris, focus, zoom: fixed
- AE, white balance: auto, manual override by PTZApp
- Lens focal length: 3.37 mm +/- 5%
- Lens F#: 2.8
- Field of view: diagonal 94°, horizontal 85°, vertical 55°
- S/N ratio: > 50dB
- Minimal illumination: 1.4 lx (50 IRE, F2.8, shutter 1/30)
- 2D noise reduction
- Back light compensation
- Minimum working distance: 80cm
- Motor pan and tilt, total horizontal viewing area 165°; vertical viewing area 85°
- Digital zoom rate: up to 4X leveraging 4K sensor
|
| Audio |
- 2 uni-direction microphones w/ 4 m recommended (6 m max) pickup range
- 5W stereo full range speakers with professional bass port tuned for communication
- Volume up to 96dB SPL at 1/2 meter
- Echo cancellation
- Noise suppression
- 3.5mm Line-in (aux) cable connects to BYOD smartphones or PC as speakerphone
|
| HDMI |
- DisplayLink USB 3.0 to HDMI adapter built-in
- 1080p HDMI output to TV**
- (**) Some limitation applied by Mac OSX and Windows inbox driver
|
| Remote Control |
|
| System Requirements |
- Windows 7/8/8.1/10
- Mac OS X 10.7 or higher
|
| Hardware Requirements |
- 2.4GHz Intel Core 2 Duo processor
- 2GB RAM or more
|
| Video Format |
|
| Compatible Applications |
- Adobe Connect, Blue Jeans, Cisco WebEx®, Google Hangout, GoToMeeting™, Intel® Unite™, Microsoft® Lync™, Skype™, Skype for Business, V-Cube, vMix, WebRTC, Wirecast, XSplit, ZOOM
|
| Power Supply |
- AC 100V ~ 240V
- Consumption: DC12V/5A
|
