RP. 56,100,000
1080p Full HD / 720p HD images up to 60 fps*1 Super high resolution at Full HD / 1,920 x 1,080 created by high sensitivity MOS Sensor. Multiple H.264 (High profile) streams (max. 4 streams) and JPEG streams ensure simultaneous real time monitoring and high resolution recording. Maximum Screen Size is 2,048 x 1,536* @30 fps, H.264 *Used by super resolution techniques Enhanced Super Dynamic*1 and ABS (Adaptive Black Stretch) technologies deliver 133 dB wider dynamic range compared to conventional cameras. Multi process NR & 3D-DNR ensures noise reduction in various conditions. High sensitivity with Day & Night (IR) function : 0.06 lx (Color), 0.02 lx (B/W) at F1.6 IR LED equipped : The equipped infrared LED makes it possible to take pictures at zero lx. IR LED is controlled to match the environment, thereby the camera provides clear images of human faces without white blur.
| Image sensor | 1/3 MOS |
| Supported Video Codec | H.264 / JPEG |
| Max. Resolution | 1080p / 2048 x 1536 |
| Max. FPS H.264 | 30 |
| Super Dynamic / WDR / BLC | Enhanced Super Dynamic |
| Day/Night | Day & Night (ICR) |
| ABF (Auto Back Focus) / Focus Assist | ABF |
| IR LED | Yes |
| Min. Illumination Color (lx) | 0.06 |
| Min. Illumination B/W (lx) | 0 |
| Lens | f=9-22mm, F1.6 Motorized |
| Angular field of view | H: 13.8-33.5 deg. V: 7.7-18.1 deg. |
| Pan/Pan Range | -100 - +100 deg. |
| Tilt/Tilt Range | -90 - +30 deg. |
| Optical Zoom | 2.4x |
| With Extra Zoom | 7.2x |
| Audio | 2-Way (No Built-in MIC) |
| External I/O | 2-Mar |
| Vandal Resistant | - |
| Water and Dust Resistance | IP66, NEMA 4X |
| Rain Wash Coating | - |
| Smart Coding | Yes |
| Temperature (degree, Celsius) Max | 50 |
| Temperature (degree, Celsius) min | -45 |
| Power Source | PoE, 12V DC |
- High Speed ABF (Auto Back Focus) and Motorized Zoom ensures easy installation.
- Face Super Dynamic technology ensures clear face image.
- Electronic sensitivity enhancement : Auto (Up to 16/30s) / OFF
- Double SDXC/SDHC/SD Memory card slots for manual recording (H.264 / JPEG), alarm recording (H.264 / JPEG) and backup upon network failure (H.264 / JPEG). Realize long-term recording and auto backup function.
- Face detection function detects the position of human face and the information is sent by XML or video stream. (Extension Software)
- Can be added new intelligent extension software in addition to built-in VMD (Video Motion Detection), alarm function.
- Fog compensation function equipped as standard.<
- Super Chroma Compensation function realizes a better color reproducibility even in low illumination.
- Supports SSL, DDNS (viewnetcam, RFC2136)
- IP66 rated water and dust resistant. Compatible with IEC60529 measurement standard,Type 4X(UL50), NEMA 4X compliant.
- Dehumidification device for use with various weather conditions
*1 Super Dynamic function is automatically set off on 60 fps mode
