RP. 93,500,000
• HD 1920x720 60fps. • 40x optical zoom • Durable Pan/Tilt gear mechanism. • Intelligent Auto (iA) feature provides increased discernibility even in environments with poor visibility. • Extreme Super Dynamic technologies deliver 144 dB wide dynamic range. • Color night vision (0.0007 to 0.011 lx).
|
Indoor / Outdoor |
Indoor |
|
|---|---|---|
|
Image sensor |
1/2.8 MOS |
|
|
Min. Illumination Color (lx) |
0.011 |
|
|
Min. Illumination B/W (lx) |
0.005 |
|
|
Maximum Resolution |
HD (720p / 1,280x 960) |
|
|
Maximum FPS |
60 |
|
|
Super Dynamic |
Yes |
|
|
Image compensation |
Adaptive Black Stretch, Back light compensation (BLC), Fog compensation, High light compensation (HLC), Digital noise reduction |
|
|
Color/BW |
ICR |
|
|
ABF(Auto back focus)/Auto Focus/Focus Assist |
Auto Focus |
|
|
IR LED |
- |
|
|
Image Stabilizer |
Yes |
|
|
Corridor Mode |
- |
|
|
Privacy Zone |
32 |
|
|
iA (Intelligent Auto) |
Yes |
|
|
Intelligent VMD (i-VMD) |
Type4 |
|
|
Focal length |
f=4.25-170mm, {5/32 - 6-11/16 inches}, F1.6 Motorized |
|
|
Zoom ratio |
40x |
|
|
Angular field of view (16:9) |
H: 1.9-66 deg. V: 1.1-39 deg. |
|
|
Angular field of view (4:3) |
H: 1.4-51 deg. V: 1.1-39 deg. |
|
|
Panning Range |
Endless |
|
|
Tilting Range |
-25 - +205 deg. |
|
|
Network IF |
10Base-T, 100Base-TX, RJ45 connector |
|
|
Video Codec |
H.265, H.264, JPEG |
|
|
Transmission mode (H.265/H.264) |
Constant bit rate, Variable bit rate, Frame rate, Best effort |
|
|
Smart Coding |
Yes |
|
|
Audio Support |
Yes |
|
|
Built-in microphone |
- |
|
|
Microphone/Line Input |
Yes |
|
|
Audio Output |
Yes |
|
|
SD memory Card Slot |
SDXC |
|
|
External I/O Terminals |
Yes |
|
|
Ambient Operating Humidity |
10-90 |
|
|
Vandal Resistant |
- |
|
|
Water and Dust Resistance |
- |
|
|
ClearSight Coating / Rain Wash Coating |
- |
|
|
Dehumidification device |
- |
|
|
Temperature (degree, Celsius) |
MAX |
50 |
| MIN |
-10 |
|
|
Temperature (degree, Fahrenheit) |
MAX |
122 |
| MIN |
14 |
|
|
Power Source |
PoE, 12V DC |
|
|
SSL device certificate |
Yes |
|
|
ONVIF Profile |
S, G |
|
Extreme image quality for evidence capturing under challenging conditions
- Long-distance vision with high power 40x zoom lens
- Sharp and clear image of fast moving vehicles with Intelligent Auto
- Outstanding low light performance in true color with low noise for night time applications
- Super Dynamic 144dB for backlit situation by headlights and shadows on the streets at night
- Long life Pan/Tilt gear mechanism
Extreme H.265 compression with new Smart Coding
- Longer recording, less storage compared to H.264 based compression techniques
- New self-learning ROI* encoding (Auto VIQS) dynamically detect motion areas to keep vehicles and human in good
picture quality while lowering your bandwidth
* Region of Interest
Extreme Data Security
- Full encryption SD card edge recording to keep your data safe
- FIPS 140-2 Level 1 compliant
- Full end-to-end system encryption with supported VMS and devices to protect from IP snooping/spoofing and detect data alteration
